Product Name:

BS100A Steel Rail

  • Standard: BS

  • Grade: UIC860V 900A

  • Rail Heigth: 152.4mm

  • Bottom Width: 133.35mm

  • Web Thickness: 15.08mm

  • Head Width: 69.85mm

  • Length: 12-30m

  • Place of Origin: China (Mainland)

  • Model Number: BS11 standard steel rail

  • Type: Heavy Rail

  • Application: Railway Rail

  • Weight: 50.18 kg/m


Share

Product Parameters

BS 100A steel rail is used for subway railway line or mining railroad line, most British Commonwealth of Nations and European country use this type of rail, the British standard is BS11-1985.

Specification: BS75A, BS90A, BS100A
Standard: BS11-1985
Material: 700/900A
Length: 8-12m

Rail TypeRail HeightFlange WidthHead Width at TopHead Width at BaseHead HeightWeb ThicknessFlange Thickness at EdgeFlange Thickness at CenterWeight (per meter)
RHFWHTHBHHWTFEFMkg
BS 75A rail128.6114.361.963.7530.512.78.315.4837.46
BS 90A rail142.912766.768.8333.513.99.117.0745.1
BS 100A rail152.4133.3569.8572.1435.8115.089.5216.2750.18
