| Description | Material | Specification | Theoretical WeightKg/m | Length | |||
| Type | H*W | Web | t | ||||
| I-Beam | Q235B | 18 | 180*94 | 6.5 | 10.7 | 24.143 | 9m/12m |
| 20a | 200*100 | 7 | 11.4. | 27.929 | |||
| 20b | 200*102 | 9 | 11.4 | 31.069 | |||
| 25a | 250*116 | 8 | 13 | 38.105 | |||
| 25b | 250*118 | 10 | 13 | 42.03 | |||
| 28a | 280*122 | 8.5 | 13.7 | 43.492 | |||
| 28b | 280*124 | 10.5 | 13.7 | 47.888 | |||
| 30a | 300*126 | 9 | 14.4 | 48.084 | |||
| 30b | 300*128 | 11 | 14.4 | 52.794 | |||
| 30c | 300*130 | 13 | 14.4 | 57.504 | |||
| 32a | 320*130 | 9.5 | 15 | 52.717 | |||
| 32b | 320*132 | 11.5 | 15 | 57.741 | |||
| 32c | 320*134 | 13.5 | 15 | 62.765 | |||
| 36a | 360*136 | 10 | 15.8 | 60.037 | |||
| 36b | 360*138 | 12 | 15.8 | 65.689 | |||
| 36c | 360*140 | 14 | 15.8 | 71.341 | |||
Remarks: Trace element, like B, Cr, can be added according to the client requirement
